Outdoor UTP cat6 Black PVC+PE jacket 0.51mm BC 8 core Network cable

Product Categories

SHENZHEN XINTAIYUE COMMUNICATION CABLE CO.,LTD.

Contact Now

Outdoor UTP cat6 Black PVC+PE jacket 0.51mm BC 8 core Network cable

Name: Outdoor UTP cat6 Black PVCPE jacket 051mm BC 8 core Network cable
Brand: WONTERM
Price: 1 USD

China Outdoor UTP cat6 Black PVC+PE jacket 0.51mm BC 8 core Network cable wholesale

Brand Name : WONTERM

Model Number : WT6803-or

Certification : CE/FCC/UL/ROHS

Place of Origin : China

MOQ : 30pcs

Price : negotiation

Payment Terms : T/T or western Union

Supply Ability : 2500pcs per month

Delivery Time : 10 working days after received your payment

Packaging Details : First packed in box and then put two boxes in one Carton.

Jacket : PVC(LSZH)+PE

Insulation : Solid polyolefin

Nominal Outer Diameter : 6.0mm

Number of Conductors : 8

Length per Box : 305M (500M/1000M...)

Contact Now

Outdoor UTP cat6 Black PVC+PE jacket 0.51mm BC 8 core Network cable

Specifications:

1. BC: Bare Copper

2. Rated Temperature:75°C

3. Various lengths and colors are available

Customers' specifications are welcomed.

CAT6 UTP/FTP/SFTP SOLID CABLE
Insulation Resistance			Min. 5000 mega-ohms-km at 20°C
Dielectric Test			1000V DC/min, Bo Breakdown
Temperature Rating			75°C
Voltage Rating			30V
Frequency	Zin-OS	Fitted Z	SRL.MIN	ATT.MAX	DELAY.MAX	DELAY.MAX SKEW	NEXT.MIN	PSNEXT.MIN
(Mhz)	(Ohm)	(Ohm)	(dB)	(dB/100m)	(ns/100M)	(ns/100M)	(dB)	(dB)
1	100 ± 15	100 ± 15	20.00	1.84	68.00	65.00	74.30	72.30
4			23.10	3.69	56.00	53.00	65.27	63.27
8			24.52	5.26	49.90	46.90	60.75	58.75
10			25.00	5.89	48.00	45.00	593.00	57.30
16			25.00	7.51	43.90	40.90	56.24	54.24
20			25.00	8.43	42.00	39.00	54.78	52.78
25			24.32	9.47	40.00	37.00	53.33	51.33
31.25			23.64	10.64	38.10	35.10	51.88	49.88
62.5			21.54	15.36	32.10	29.10	47.36	45.36
100			20.11	19.78	28.00	25.00	44.30	42.30
200			18.00	28.97	22.00	19.00	39.78	37.78
250			17.32	32.84	20.00	17.00	38.33	36.33

What is the application of the cable ?

- Computer network cabling project

- Broadband network communication

- Ethernet network

-Audio and data transmission

-10/100 Base-T4

-100Base-TX

-1000Base-T(Gigabit Ethernet)

-155Mbps ATM

-622Mbps ATM

Trade term:

Payment	T/T,L/C,D/P,D/A,Paypal,Western Union,MoneyGram,based on your quantity
Delivery time	Within 7 days,finally based on your quantity
Sample	Sample is free,we cooperate with DHL,TNT,UPS,FEDEX,EMS,China Air Post, ect
Discount	We can offer when your order is over 100 boxes

Outdoor UTP cat6 Black PVC+PE jacket 0.51mm BC 8 core Network cable

Product Tags:

outdoor cat6 cable shielded

outdoor ethernet cable cat6

Outdoor UTP cat6 Black PVC+PE jacket 0.51mm BC 8 core Network cable Images
